Turbine SparesDibuat Sesuai Pesanan

Saklar Tekanan Diferensial dan Suhu Oli Pelumas Turbin Uap

Indicative Price Range

₹3.5K–₹22Kper piece

Switch DP & suhu; bagian basah SS; IP65/67

Get Quote

Prices vary by turbine make and model, OEM spec, material grade, and order quantity. The range shown reflects our typical market spread — contact us for a firm quotation.

Switch tekanan diferensial (DP) dan switch suhu untuk pemantauan kondisi housing filter oli pelumas turbin, panel changeover filter duplex, heat exchanger, dan perpipaan proses. Switch DP memberi sinyal penyumbatan elemen filter dengan mendeteksi tekanan diferensial yang meningkat pada elemen yang tersumbat — memungkinkan perawatan terencana sebelum bypass elemen terjadi dan oli tidak tersaring mencapai bearing turbin. Switch suhu memberikan output alarm dan trip tinggi/rendah untuk suhu oli pelumas, suhu logam bearing, dan pemantauan suhu aliran proses.

Primary Industrial Application

Pemasangan langsung atau retrofit pada housing filter duplex Keshav Enterprises yang ada (seri Elemen Filter Oli Pelumas Turbin Pengganti Triveni, Elemen Filter Oli Pelumas Turbin Pengganti Siemens) dan basket strainer simplex — disambungkan ke DCS pabrik, PLC, atau panel alarm lokal untuk pemantauan kondisi filter. Juga digunakan pada housing filter pihak ketiga, pemantauan suhu inlet/outlet heat exchanger, kontrol suhu outlet pendingin oli pelumas turbin, dan sirkuit alarm/trip suhu bearing turbin uap. Output switch DP memicu alarm changeover filter (duplex) atau alarm perawatan (simplex/basket) sebelum katup bypass terangkat dan oli tidak tersaring bersirkulasi ke bearing.

DP Setpoint Range0,3–10 bar (standar)
Temperature Setpoint Range–20°C hingga +200°C
Process Connection½" BSP/NPT male (standar); ¼" BSP atas permintaan
Est. Price₹3.5K – ₹22KIndicative estimate · contact for firm quote
Lead Time2–6 weeks (standard); custom 6–10 weeks

Price & Lead Time shown on every tab

Request Quote via WhatsApp

Scoped to this part for a fast reply. For general inquiries, use our Contact page instead.

PDF, DWG, DXF, JPG, PNG — max 10 MB per file. Helps us quote faster.

We respond within 1 business day · No spam · Privacy Policy

Need installation or maintenance?

Our field engineers supply, install, and commission everything we sell.

View engineering services

Technical details we need to quote

  • Equipment make and model, or the part number you currently use
  • A drawing or a clear photo of the part or its nameplate
  • Quantity required

Send these on the contact form or by WhatsApp.
